Sunsynk 12kW 3 Phase Hybrid Inverter 48V Incl Wifi Dongle

Sunsynk 12kW 3 Phase Hybrid Inverter 48V Incl Wifi Dongle
SUNSYNK 12kW Hybrid Inverter (3 Phase) – SUN-12K-SG04LP3
Model SUN-12K-SG04LP3
Wi-Fi Ready – works via Sunsynk App.
Complete with Wi-Fi Dongle for Remote Monitoring & Changing Parameter via App.
The Synsynk Hybrid Parity Inverter is a Highly Efficient Power Management Tool.
Manages Power Flow from multiple sources such as Solar, Main Power (Grid) & Generators, then effectively storing & releasing power as & when utilities require.
Easy & Simple to Understand LCD Display.
Wi-Fi & GSM monitoring supported.
Equipped with Visual power flow screen.
Built-In 2 strings for 1 MPP tracker & 1 string for 1 MPP tracker.
Smart settable 3-stage MPPT charging – optimised battery performance.
Auxiliary load function.
Parallel (coming soon)/multi-inverter function – grid-tied & off-grid.
230V/400V Three-Phase Pure Sinewave Inverter.
Grid Type: Three Phase.
Protection Degree: IP65
Noise Level: <30dB
Maximum Charge & Discharge Current: 240A
Battery Charging Strategy: Self-Adaptation to BMS
Maximum DC Input Power: 15000W
MPPT Range: 140-800V
Start-up Voltage: 160V
AC Output & UPS Power: 12000W
Maximum AC Power: 13200W
AC Output Rated Current: 17.4A
Maximum AC Output Current: 19.1A
Maximum Efficiency: 97.60%
MPPT Efficiency: 97.0%
Battery Type: Lead-acid or Lithium-ion (Not Included – Sold Separately)
Battery Voltage Range: 40-60V
Communication with BMS: CAN/RS485
Fan Cooling
Operation Temperature: -25°C to 60°C
Installation Type: Wall Mounted.
Weight: 45Kg
Dimensions (L x W x H): 673 x 462 x 265 mm
Does Not Include Power Cables & Communication Cables (Sold Separately)
Refer To Brochure For Detailed Product Specifications.
Product might vary from depicted images.
Graphics are for illustrative purposes only.
