Hy-brid solar inverter 1600 watts

Description
Additional information
The Gentech Power 1600 Watt Hybrid Solar & AC Inverter System has a built in solar controller.
A solar panel can be connected to the unit to charge the battery.
The solar panel is NOT included.
The recommended panel size is: 2 x 375-390 Watt Panel

Perfect For:
Tv
Laptop
Monitor
WiFi Router
Decoder
LED Lamps
Cellphone charger

Model: 2000VA(1600W) 24V

Input
Nominal Voltage: 220-240VAC
Input Voltage Range: 90-280VAC
Nominal Frequency: 50Hz or 60Hz (Auto Detection)

Solar
Nominal Voltage: 36Vdc
Charging Current: 50A 1Amax.

Output
Voltage: 230VAC 10%
Frequency: 50/60Hz 0.1Hz

Waveform
Modified: Sine-wave
Efficiency (AC to AC): 95%
Effigie (DC to AC): 80%

Battery
Nominal Voltage: 24Vdc

Charger
Charging Voltage:28.8Vdc
Charging Current:1OA/20A 2A max.

Overcharging Protection: 32.0V

Transfer
Transfer lime:15-20ms typical (narrow range); 40ms max (wide range)

Audible Alarm
Low Battery Voltage in Battery Mode: Buzzing every 2 seconds
Overload: Buzzing every 0.5 seconds
Fault: Buzzing continuously

Environment
Temperature: o-4oc

Key Features:
– Easy to use plug and play – no wiring.
– 3 SA plug points positioned above the unit for easy plug access

Hybrid Solar & AC Technology.
– Low Heat Dissipation.
– Features dual charging from both solar and AC mains.
– Provides uninterrupted power during load-shedding.
– Portable, has wheels to move from one to room to another easily.
– Batteries housed in a metal cabinet on castors.

Dimensions & Weight
Length: 435mm
Width: 420mm
Height: 500mm
Weight: 77.8Kg
