Sandvik Dr560 drill rig

Sandvik DR560 Drill rig 2011 model Only 1900 hours Key Specs Engine / Power: Turbo-charged diesel (model QSK 23, Tier II) providing 641 kW (≈ 860 hp) at 1,800 rpm. Compressor / Air delivery: Working pressure up to ~34.5 bar (500 psi). Free air delivery (FAD) at 1,800 rpm: ~543 l/s (1,150 cfm). At 2,100 rpm / 24.1 bar (≈350 psi): ~637 l/s (1,350 cfm). Hole / drilling range: Hole diameter: min ~115 mm (4.5 in) up to ~216 mm (8.5 in). Hammer size (minimum): ~102 mm (4 in). Hole (carousel) depth without adding drill pipe: ~42.6 m (≈140 ft) for the standard configuration. Rotational / Top drive: Rotation torque: ~5,730 Nm (≈4,225 ft-lb) in standard top drive. Option for ~8,515 Nm (≈6,280 ft-lb). Rotation speed: 0-80 rpm variable. Transport / dimensions / weight: Length: ~11,405 mm (~44.9 ft) Width: ~3,000 mm (~118 in) Height: ~3,810 mm (~150 in) Operating weight (empty, wet, excluding drill pipes): ~33,112 kg (~73,000 lbs) Mobility / undercarriage: Ground clearance: ~530 mm (~21 in) Gradeability: ~35% (depending on configuration) Other specs / features: Track oscillation: ±10° (independent) Operator cabin: FOPS approved, sound-insulated (<82 dB), 360° viewing windows, adjustable seat with vibration isolators. Standard rod carousel capacity: typically 6 rods of length 6.1 m (20 ft) in standard config.
