Vibe amp

amplifier technology allows us to deliver high performance in an incredibly small footprint. Our mono & 4 channel Powerbox micro amps are small, yet mighty, with up to 400w for bass and 4 x 65w for speakers. The small size enables easy installation. The 4 channel features a +12v remote output and daisy chain signal output making it an ideal system building block.



The 4 channel amp has the option to fit with ISO T harness direct to the head unit this supplies audio signal and power and earth meaning there is no need to connect a separate cable through to the vehicles battery, just plug and play. For the bass amp, an ISOAWK kit (available separately) is available that can be purchased with the amp to make it compatible with an ISO T harness to plug into the existing stereo loom in the vehicle just like the 4 channel.



Amplifies and upgrades almost any OEM or aftermarket radio

The biggest output micro amp on the market

Plug and Play adapters available for ease of install

Molex to ISO connection included to connect to OEM unit

Specification



Type



4-Channel Micro Power Amplifier



Class



D



Power Handling



4 x 65w @ 4 ohm



4 x 195 @2 ohm



2x 390 @4ohm



1x 520 watts Max



Dimensions (H x W x D)



1.5″ x 7.4″ x 3.2″ (37mm x 187mm x 82mm)



Frequency response



50Hz – 20kHz



Crossover type



HP/Full



Crossover range



50Hz Class D micro amplifier



Weight



1.07 kg



Dimensions



3.7 x 18.7 x 8.2 cm
